Special Carbon Primer - P510 Primer

P510 Carbon primer

Use / destination:

Suitable for bike frames, fairings, carbon structures, snowboards, windsurfing boards, and similar applications.

Thanks to its special formulation, this is the only product that guarantees adhesion and prevents peeling on carbon substrates.

It is used exclusively on bare carbon, before paint application and after any repair with a carbon filler, for example.

Nature of the product:

P510 is a solvent-based, two-component acrylic epoxy primer.

It is a fine, transparent, easy-to-apply matt product that dries quickly.

Shade: Matt and transparent, it helps preserve the visible weave of the carbon fibres beneath.

The P510 carbon primer is a two-component clear primer with direct adhesion capability. Its key advantage is its transparency.
We also offer P410 Primer available in opaque white, grey or black, which adheres equally well to carbon substrates.

Packagings:

0.7 L Kit: Includes 0.5 L primer, 100 ml H423 hardener, 100 ml thinner

1.4 L Kit: Includes 1 L primer, 250 ml H423 hardener, 250 ml thinner

7 L Kit: Includes 5 L primer, 1 L H423 hardener, 1 L thinner

Substrate preparation:

Sand with P400–P500.

Clean with water and dry thoroughly using a heat source.

Degrease with alcohol or an appropriate degreaser.

Mixture:

Primer (by volume): 100 parts

Hardener: 20 parts

Thinner: 20 parts

Application Viscosity: 18–20 s CA No.4 at 20°C

Spray gun application:

Nozzle diameter: 1.0–1.4 mm

Pressure: 2.5–4 bar

Carbon 8070T Primer application:

Apply over a smooth, finely sanded surface (P320–P500).

Apply 1 to 2 coats, allowing 5–10 minutes between coats.

Recoatable without sanding: 2 hours

Dry film thickness: 10–30 μm

Desolvation time: 5 minutes

Storage: 24 months in original sealed packaging.

Storage temperature: between 10°C and 30°C.

Theoretical coverage: 8 m²/L

VOC: > 420 g/L

If you prefer a fast-drying, one-component carbon primer that is non-transparent, use the 1K grey primer P440

Question:

Is it possible to sand the carbon primer?

Yes, it is a sandable product, like any paint or varnish.

However, it is not a filling primer and should not be used as such.

It is designed for adhesion, not surfacing.

If you require a thick, self-levelling, sandable, and transparent product, we recommend the 4000 Thick epoxy resin / varnish
