SATAJET 5000 B HVLP - 1.3 SATA SPRAY GUN FOR BASES

SATAJET 5000 B HVLP is a spray gun specially designed for base application.

It’s part of the new generation of ATA spray guns offering high transfer rate (86%) and unequalled robustness.


The SATAJET 5000 B HVLP is equipped with a very flexible trigger for an optimal grip.

Thanks to the simplified round/flat spray adjustment in half a turn, exceptional pattern width and fineness can be achieved.

The "super-economic" SATAjet 5000 B HVLP provides particularly high transfer rates with its low-pressure technology.




The new Pearlchrome coating (6 surface treatments including protection against corrosion) and the metal adjustment buttons simplifies cleaning of SATA 5000 B HVLP to maximum.
Easy needle assembly and disassembly using the new Guide.

Available in 2 versions:
- Standard
- Digital

The digital version ensures optimum pressure adjustment.
Digital pressure indication for precise adjustment, maximum colour accuracy and good reproducibility of the application result.





Package Contents:
- SATAJET 5000 B HVLP
- 3 disposable buckets: 0.3L, 0.6L, 0.9L (one of each)
- Tool Kit (Universal wrench, Multi-tool, Cleaning Brush, Clips Color Code System, Paint Sieve, Air distribution ring extraction pin) Simplified round/flat spray adjustment in half a turn


Technical informations:

- 1.3mm nozzle
- 3 disposable buckets: 0.3L, 0.6L, 0.9L (one of each)
- Weight: 476g (without bucket)
- 1/4GM Air connector
- Working air pressure: 1.8-2.0bar
- Air consumption: 430L per minute
- Projection distance: 12-15c
